Navigation system with LED for easy and simple operation
High internal resolution 1/600,000 (HC-3Ki / 6Ki / 30Ki) and 1/750,000 (HC-15Ki)
Weighing display resolution 6000 (HC-3Ki / 6Ki / 30Ki) and 7500 (HC-15Ki)
Automatic Counting Accuracy Improvement (ACAI)
Audible Weighing Assist beeping function (AWA)
Detachable display unit
Comparator function with “HI”, “OK”, “LO” display
Optional Sealed Lead Acid (SLA) rechargeable battery
Accumulation function

Up to 99 unit weights ID memory function
Universal Flex Coms function
Auto-power OFF function
Full Digital Calibration function
Large LCD display (height – 18.6mm for pieces / 11.4mmt for weight and unit weight)
Simple operation mode
Large stainless steel weighing pan ( 300 x 210 mm / 11.8 x 8.3 inches)
Optional Interface function RS-232C and Relay output

	HC-3Ki	HC-6Ki	HC-15Ki	HC-30Ki
Capacity (lb)	6lb	15lb	30lb	60lb
Resolution (lb)	0.001lb	0.002lb	0.005lb	0.01lb
Capacity (kg)	3kg	6kg	15kg	30kg
Resolution (kg)	0.0005kg	0.001kg	0.002kg	0.005kg
Sample Size	10 pieces normal -5, 25, 50, 100, or random number, user selectable
Min. Unit Weight*	0.1g / 0.005g	0.2g / 0.01g	0.4g / 0.02g	1g / 0.05g
Internal Resolution	1 / 600,000		1 / 750,000	1 / 600,000
Non-linearity	±0.5g	±1g	±2g	±5g
Repeatability	0.5g	1g	2g	5g
Span Drift	0.002% / °C (5°C ~ 35°C) typ.
Operating Temp.	-10°C to 40°C / 14°F to 104°F, 85%RH or lower (No condensation)
Display	7 segment LCD, Character height: pcs 18.6mm, weight / unit weight 11.4mm
Display Update	Approximately 10 times per second
Max. Count Display	600,000		750,000	600,000
Interface	RS-232C (Option)
Power	AC adapter or SLA Battery (Option) Battery Operating Time: Approx. 80-hour (without interface)
Platform Size	300 x 210mm / 11.8 x 8.3 inches
Dimensions	315(W) x 331(D) x 126(H) mm / 12.4(W) x 13(D) x 5(H) inches
Weight (approx.)	4.8kg / 10.6lb
Calibration Weight	3kg ±0.1g	6kg ±0.2g	15kg ±0.5g	30kg ±1g
Standard Accessories	Instruction manual, AC adapter
