MX1101

HOBO Temperature/Relative Humidity Data Logger – MX1101

Hubungi Kami

Untuk meminta informasi produk dan pemesanan, anda bisa menghubungi marketing kami di Whatsapp melalui tombol diatas atau melalui:

Telepon: 021 8690 6777

Email: sales@timbanganindonesia.com

Category:

Description

Onset HOBO MX1101 Data Logger mengukur dan mentransmisikan data suhu dan kelembaban relatif secara nirkabel ke perangkat seluler melalui teknologi Bluetooth Low Energy (BLE).

Pencatat data nirkabel bekerja dengan perangkat seluler Anda dan aplikasi HOBOconnect gratis dari Onset sehingga Anda dapat mengonfigurasi pencatat dan membaca data dalam jarak 100 kaki, tanpa memerlukan peralatan khusus lainnya. Anda juga dapat melihat data dalam grafik, memeriksa status operasional logger, mengonfigurasi pemberitahuan alarm, dan berbagi file data.

Tambahkan MX Gateway untuk akses jarak jauh ke data Anda di perangkat lunak HOBOlink berbasis cloud Onset.

  • Komunikasi nirkabel melalui teknologi Bluetooth Low Energy (BLE)
  • Mudah digunakan dan dibongkar menggunakan aplikasi HOBOconnect gratis
  • Alarm akan muncul apabila melewati ambang batas tinggi dan rendah
  • Menyimpan 84.000 pengukuran
  • Akurasi: +/- 0.2C dan +/- 2% RH
  • Fitur find-me
  • Teknologi konektivitas yang dipatenkan
Temperature Sensor
Range -20° to 70°C (-4° to 158°F)
Accuracy ±0.21°C from 0° to 50°C (±0.38°F from 32° to 122°F)
Resolution 0.024°C at 25°C (0.04°F at 77°F)
Drift <0.1°C (0.18°F) per year
RH Sensor*
Range 1% to 90%, non-condensing
Accuracy ±2.0% from 20% RH to 80% RH typical to a maximum of ±4.5% including hysteresis at 25˚C (77˚F); below 20% RH and above 80% RH ±6% typical
Resolution 0.01%
Drift <1% per year typical
Response Time
Temperature 7:30 minutes in air moving 1 m/s (2.2 mph)
RH 20 seconds to 90% in airflow of 1 m/s (2.2 mph)
Logger
Radio Power 1 mW (0 dBm)
Transmission Range Approximately 30.5 m (100 ft) line-of-sight
Wireless Data Standard Bluetooth Smart (Bluetooth Low Energy, Bluetooth 4.0)
Logger Operating Range -20° to 70°C (-4° to 158°F); 0 to 95% RH (non-condensing)
Logging Rate 1 second to 18 hours
Logging Modes Fixed interval (normal, statistics) or burst
Memory Modes Wrap when full or stop when full
Start Modes Immediate, push button, date & time, or next interval
Stop Modes When memory full, push button, date & time, or after a set logging period
Restart Mode Push button
Time Accuracy ±1 minute per month at 25°C (77°F)
Battery Life 1 year, typical with logging interval of 1 minute. Faster logging and/or statistics sampling intervals, entering burst logging mode, and remaining connected with the app will impact battery life. Excessive readouts, audible alarms, and paging all impact battery life. Visual alarms and other events can have a marginal impact on battery life.
Battery Type Two AAA 1.5 V alkaline batteries, user replaceable
Memory 128 KB (84,650 measurements, maximum)
Full Memory Download Time Approximately 60 seconds; may take longer the further the device is from the logger
LCD LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range
Size 3.66 x 8.48 x 2.29 cm (1.44 x 3.34 x 0.9 in.)
Weight 56 g (1.98 oz)
Environmental Rating IP50
CE Compliant The CE Marking identifies this product as complying with all relevant directives in the European Union (EU).
