| Low-profile | Integrated loading base |
| Low-deck high capacity scale applications | |
Special Load Cell CPA
Untuk meminta informasi produk dan pemesanan, anda bisa menghubungi marketing kami di Whatsapp melalui tombol dibawah atau melalui:
Telepon: 0813-134-9146
Email: sales@timbanganindonesia.com
| Max. Capacity | 500kgf, 1, 1.5, 2, 3, 5tf |
| Rated Output | 1.7 ± 0.17mV/V |
| Zero Balance | 0 ± 0.016mV/V |
| Combined Error | 0.14%RO |
| Repeatability | 0.03%RO |
| Creep for 30 min | 0.03%RO |
| Temperature Effect on : Zero Value Output Value |
0.03%RO/10°C 0.05%RO/10°C |
| Excitation : Recommended Maximum |
10V 15V |
| Resistance : Input Output Insulation |
760 ± 7Ω 700 ± 7Ω ≥ 2.000MΩ |
| Compensated Temperature Range | – 10 ~ 40°C |
| Operating Temperature Range | – 40 ~ 70°C |
