• STAINLESS STEEL HOUSING AND WATER PROOF
• HIGH PRECISON A/D CONVERSION WITH READABILITY 1/30000
• SPECIAL DIGITAL FILTERING TECHNOLOGY TO STRENGHTEN ANTI-VIBRATION ABILITY
• CALL AND DISPLAY INNER CODE TO REPLACE WEIGHT OBSERVING AND ANALYSIS TOLERANCE
• SET-UP ZERO TRACKING RANGE, ZERO (AUTO/MANUAL) RANGE AND ZERO SPEED
• SET UP DIGITAL FILTER INTENSITY, RANGE, AND STABLE TIME
• ALARM FOR LOW BATTERY AND AUTO POWER OFF AT LOW BATTERY
• AC/DC POWER SUPPLY WITH BUILT-IN RECHARGEABLE 6V/4AH BATTERY
• SERIAL COMMUNICATION INTERFACE RS 232 WITH SELECTABLE BAUD RATE BY CONTINUOUS SENDING METHOD OR ON COMMAND METHOD

A/D CONVERSION METHOD: Σ – Δ

A/D CONVERSION SPEED: 10 TIMES/SEC.

MAX. A/D CONVERSION BITS: 20

INPUT SIGNAL RANGE: -10mV ~15mV

INPUT SENSITIVITY: ≥ 1 µV/e

LOAD CELL EXCITATION: DC 5V; 1≤150мА

MAX.CONNECTION NUMBER OF LOAD CELL: 4 AT 350 онм

LOAD CELL CONNECTION MODE: 4 WIRE

VERIFIED COUNTS: 3000

MAX. EXTERNAL COUNTS: 30000

MAX.INTERNAL RESOLUTION: 300000

DIVISION: 1/2/5/10/20/50 OPTIONAL
