SPECIFICATIONS

Sample rated      : 5-25 times/sec

Load cell sensitivity          : 1-2mv/v

Division                : 1/2/5/10/20/50/100 optional

Display                 : 7-bits LED digital display 0.56″ in character height and 7 status indicating

Clock     : can display day/month/year and second/minute/hour

Scoreboard display interface : Using serial output method current loop signal, transmission distance $50m RS323 signal, transmission distance $30m

Communication port       : RS-232C. Baud rate: 600/1200/2400/4800/9600 optional

Printing Port : Standard parallel output port, can connect with Tpup 16 micro-printer, TM800,LX- 300, KXP-1121and LQ-1600k wide-line printer.

Power Supply                                     : AC 187-242V 49-50Hz The built-in repair-proof storage cell; 12V 7AH

Operating Temperature and Relative Humidity     : D-40°C ≤90% RH

Storage/transportation Temperature                       : -20-50

Fuse                                                                                       : 500mA
